>> Optional Taiwan TJR NC rotary table for 4th axis to process round pieces, and realize 4-axis linkage.
 |
High Precision and Gantry Type Milling Machine 4300x2700x3300 for CNC Machining Center
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMAC TIMEWAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $153,000.00/sets 1-1 sets |
|
Detail Information |
|||
| Condition: | New | Spindle Taper: | BT40 |
|---|---|---|---|
| No. Of Spindles: | Single | Type: | VERTICAL |
| Dimension(L*W*H): | 4300x2700x3300 | Weight (T): | 3 KG |
| Table Size (mm): | 320x800 | CNC Control System: | GSK |
| Table Travel (X) (mm): | 1000 | Table Travel (Y) (mm): | 600 |
| Table Travel (Z) (mm): | 1400 | Positioning Accuracy (mm): | 0.04mm |
| Repeatability (X/Y/Z) (mm): | 0.008 | Range Of Spindle Speed(r.p.m): | 0 - 6000 R.p.m |
| Max. Table Load(kg): | 1500 Kg | Feed Speed(mm/min): | 1 - 100 Mm/min |
| Min. Time Of Tool Change(s): | 2 | Tool Magazine Capacity: | 16, 24 |
| Key Selling Points: | Multifunctional | Warranty: | 1 Year |
| Voltage: | Customer's Requirement | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Machining Capacity: | Heavy Duty |
| Spindle Bore(mm): | 130 | Cutting Torque: | 38 N.m |
| Rapid Feed Speed(mm/min): | 1 - 100 Mm/min | Table Width: | 900 |
| Table Length: | 1300/1600/1800/2000/2200 | T-slot (No./width/pitch): | 5/22/165 |
| Loading Capacity: | 1500/1700/2000/2500/3000 | Longitudinal Travel (X): | 1300/1600/1800/2000/2200 |
| Cross Travel (Y): | 1000 | Vertical Travel (Z): | 600 |
| Max. Height Of Workpiece: | 1400 | Distance From Spindle Nose To Table: | 680 |
| Spindle Taper & Diameter: | 180-780 | ||
Product Description
CNC Machining Center Large Size Gantry Type Milling Machine Gantry Machining Center
Products Description
Specification | Unit | GMC1800 | GMC2200 | GMC2700 |
Table width | mm | 1600 | 2000 | 2300 |
Table length | mm | 2000/2500/3000/3500 | 3000/4000/5000 | 3000/4000/5000/6000 |
T-slot (No./width/pitch) | mm | 9/22/180 | 9/22/200 | 11/28/200 |
Loading capacity | kg | 6000/7000/8000/9000 | 10000/12000/14000 | 10000/12000/15000/18000 |
Longitudinal travel (X) | mm | 2000/2500/3000/3500 | 3000/4000/5000 | 3000/4000/5000/6000 |
Cross travel (Y) | mm | 1800 (2000) | 2200 (2700) | 2700 (3050) |
Vertical travel (Z) | mm | 1000 | 1000 | 1000 |
Gantry width | mm | 1800 | 2300 | 2700 |
Max. height of workpiece | mm | 1300 | 1400 | 1400 |
Distance from spindle nose to table | mm | 150-1150 | 280-1280 | 280-1280 |
Spindle taper & diameter | - | BT50/Φ190 | BT50/Φ200 | BT50/Φ200 |
Spindle speed | rpm | 6000 | 6000 | 6000 |
X/Y/Z-axis feed speed | m/min | 10/10/10 | 8/8/8 | 6/6/6 |
X/Y/Z-axis rapid feed speed | m/min | 15/15/15 | 12/12/12 | 10/10/10 |
X/Y/Z-axis feed motor torque | N.m | 38/30/30 | 50/40/30 | 50/40/30 |
X/Y/Z-axis positioning accuracy | mm | 0.025/0.02/0.018 | 0.025/0.02/0.018 | 0.025/0.02/0.018 |
X/YZ-axis repetability accuracy | mm | 0.02/0.015/0.012 | 0.02/0.015/0.012 | 0.02/0.015/0.012 |
Main motor power | kw | 22 | 22 | 22 |
Tool magazine capacity | T | 24 (Disc) | 24 (Disc) | 24 (Disc) |
X/Y-axis guideway type | - | Linear | Linear | Linear |
Z-axis guideway type | - | Sliding | Sliding | Sliding |
Machine weight | tons | 21.5/24/26.5/29 | 33/38/42 | 42/46/51/62 |
Machine length | mm | 5700/6700/7700/8700 | 7750/9750/11750 | 7750/9750/11750/13750 |
Machine width & height | mm | 4030x3900 | 4740x4100 | 5140x4100 |
√ FANUC 0i MF CNC system √ X/Y: Linear guide rails, Z: Sliding guide rail √ Taiwan BT40 spindle, 8000rpm √ Taiwan disc-type ATC with 24tools √ Full enclosure √ Manual pulse generator (MPG) √ USB & LAN interface √ Work lamp √ Pilot lamp √ Cooling system √ Centralized automatic lubrication system √ Spindle air blast √ Air gun √ Milling arbor & chuck √ Heat exchanger for electric cabinet √ Tools & tool-box √ Leveling wedge & bolts √ Operation manual (English) | _MITSUBISHI/SIEMENS/FAGOR/GSK/HNC/KND _ 4th axis _ Direct driven spindle (10000, 12000, 15000rpm) _ Circular coolant nozzle _ Coolant through spindle (CTS) _ Spindle oil cooler _ Air conditioner _ Chain-type chip conveyor _ Water gun _ Safety door _ Tool measurement system _ Workpiece measurement system |
Machine Details
========================
>> Hardened and fine ground worktable surface make sure high rigidity.
========================
>> Large working space can meet the processing requirement of different size pieces.
>> Stainless steel telescopic cover can protect effectively the machine guideways and ball screw from damage.
========================
>> Choose Taiwan BT40 disc-type tool magazine, with high concentricity, low noise, fast tool change, high precision, long service life.
========================
>> Stable CNC system guarantees all working performance of the CNC vertical machining center.
>> Mitsubishi CNC system comes optional.
========================
>> Chain-type chip conveyor comes optional.
