Horizontal Slant Bed CNC Lathe AK-40P 3000x1545x1720mm Spindle Taper other
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMEWAY |
| Model Number: | AK-40P |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $33,880.00/sets 1-2 sets |
|
Detail Information |
|||
| Type: | Horizontal | Max. Length Of Workpiece (mm): | 350 |
|---|---|---|---|
| Structure: | Slant Bed Lathe | Machining Capacity: | Medium Duty |
| Max. Weight Of Workpiece(kg): | 2800 | Width Of Bed (mm): | 450mm |
| No. Of Spindles: | Single | Number Of Axes: | 2 |
| Travel (X Axis)(mm): | 470 Mm | Travel (Z Axis)(mm): | 400 Mm |
| Positioning Accuracy (mm): | ±0.002 | Repeatability (X/Y/Z) (mm): | ±0.012 |
| Dimension(L*W*H): | 3000x1545x1720mm | Tool Post Stations: | 12, 8 |
| Weight (KG): | 4900 | Warranty: | 1 Year |
| Key Selling Points: | Multifunctional, Automatic, Competitive Price, High Safety Level, High-accuracy, Energy Saving, Sustainable, High Productivity, Long Service Life, Easy To Operate, High Rigidity | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Range Of Spindle Speed(r.p.m): | 0 - 4500 R.p.m | Travel (Y Axis)(mm): | 450 Mm |
| Spindle Taper: | Other | Cutting Torque: | 125 N.m |
| Rapid Feed Speed(mm/min): | 0 - 1200 Mm/min | Feed Speed(mm/min): | 0 - 1200 Mm/min |
| Min. Time Of Tool Change(s): | 2 | CNC Or Not: | CNC |
| Machine Type: | Slant Lathe Machine | Control System: | SIEMENS GSK FANUC (optional) |
| Precision: | High Precision Machine | Product Name: | Cnc Slant Lathe Machine |
| Max. Turning Diamater: | 180mm | Max.swing Over Bed: | 450mm |
| Max. Turning Length: | 350/250mm | Main Motor Power: | 7.5kw |
| Color: | Customer Optional | ||
Product Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Product Description
Specification
SPECIFICATION | UNIT | AK-40P |
Max.swing over bed | mm | 450 |
Max. turning diameter | mm | 180 |
Max. diameter of bar | mm | 70 |
Max. turning length | mm | 350/250 |
Cross travel (X) | mm | 470 |
Longitudinal travel (Z) | mm | 400 |
X-axis rapid feed speed | m/min | 12 |
Z-axis rapid feed speed | m/min | 12 |
Spindle speed range | rpm | 4500 |
Spindle nose | - | A2-6 |
Spindle bore | mm | 87 |
Chuck size | inch | 8" |
Tool post type | - | Gang-type |
No. of station | pcs | 4-8 |
Tool section size (turning) | mm | 25x25 |
Tool section size (boring) | mm | 25 |
Power-driven tool (optional) | - | Single/Double/Three |
Main motor power | kw | 7.5 |
X-axis servo motor power | kw | 2.3 |
X-axis motor torque | NM | 7.5 |
Z-axis servo motor power | kw | 2.3 |
Z-axis motor torque | NM | 10 |
Working accuracy | mm | IT6 |
Roughness | um | Ra0.8 |
X/Z-axis positioning accuracy | mm | 0.016/0.02 |
X/Z-axis reppositioning accuracy | mm | 0.007/0.01 |
CNC system | - | GSK988T |
Machine dimensions (LxWxH) | mm | 3000x1545x1720 |
Machine weight | kg | 4900 |
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Factory Display：
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
Want to Know more details about this product
