550mm Cutting Capacity Semi Automatic Metal Band Sawing Machine with 60m/min Blade Speed
Product Details:
| Place of Origin: | China |
| Brand Name: | Timac |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $50,000.00/sets 1-2 sets |
| Packaging Details: | in wooden case (can be fumigeted) |
| Supply Ability: | 100 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Machine Type: | Band Saw Machine |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2022 | Cutting Capacity (mm): | 550 |
| Blade Speed (m/min): | 60 | Saw Blade Tension Method: | Mechanical |
| Warranty Of Core Components: | 1 Year | Core Components: | Gearbox, Pump, Motor |
| Showroom Location: | Egypt, Germany, Pakistan | Warranty: | 1 Year |
| Weight (KG): | 1500 | Applicable Industries: | Machinery Repair Shops, Manufacturing Plant |
| Key Selling Points: | Multifunctional | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Name: | Semi Automatic Horizontal Metal Band Sawing Machine | Color: | As Your Requirement |
| Voltage: | As Your Requirement | Saw Blade Hydraulic Tension: | Customized |
| Motor Main: | 5.5kw (4P) | Motor Hydraulic: | 1.5kw |
| Coolant Pump: | 0.075kw | Workpiece Clamping: | Hydraulic Vice |
| Blade Tensioning: | Manual | Port: | China Port (As Your Requirement) |
Product Description
Products Description
Features:
Double-column portal horizontal band-sawing machine series is a kind of large and middle
sized machine in automatic and semi-automatic mode widely uses for cutting ferrous and non-ferrous metals. It has the advantages of narrow sawing cut, material saving, energy saving, high sawing precision, convenient operation and high.
Model | Unit | GBS-550 | GBS-650 |
Cutting capacity | mm | 550 (550WX550H) | 650 (650WX650H) |
Blade speed | m/min | 30/50/60 | 20/45/65 |
Blade size | mm | 41x1.25x6460 | 41x1.25x6860 |
Motor main | kw | 5.5 (4P) | 5.5 (4P) |
Motor hydraulic | kw | 1.5 | 1.5 |
Coolant pump | kw | 0.075 | 0.075 |
Workpiece clamping | Hydraulic vice | Hydraulic vice | |
Blade tensioning | Manual | Manual | |
Main drive | Gear drive | Gear drive | |
Table height | mm | 510 | 510 |
Size outward (LxWxH) | mm | 3030x1585x1990 | 3270x1585x2160 |
- Blade cleaning brush - Working light - Saw frame height selector gauge - Out feed with auxiliary plate table - One piece of bi-metal saw blade - One set of tools with tool box - Roller table 1.5M long | - Automatic chip conveyor - Power roller table 2M long - Laser projector - Hydraulic blade tension - Roller table 2m long - Hydraulic shuttle table feeding |
Why Choose Us
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
Want to Know more details about this product
