Industry Gantry Machining Center with 3000mm Table Travel and 6m/min Feed Speed
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Timac |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $198,000.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Spindle Taper: | BT50 |
|---|---|---|---|
| No. Of Spindles: | 3 | Type: | Gantry |
| Dimension(L*W*H): | 7750*5140*4100mm | Weight (T): | 42 T |
| Table Size (mm): | 3000*2300 | CNC Control System: | FANUC, MITSUBISHI, KND, Siemens |
| Number Of Axes: | 3 | Table Travel (X) (mm): | 3000 |
| Table Travel (Y) (mm): | 2700 | Table Travel (Z) (mm): | 1000 |
| Positioning Accuracy (mm): | ±0.005 | Repeatability (X/Y/Z) (mm): | ±0.003 |
| Spindle Motor Power(kW): | 22/26 | Max. Table Load(kg): | 10000 Kg |
| Min. Time Of Tool Change(s): | 2 | Tool Magazine Capacity: | Other |
| Key Selling Points: | Competitive Price | Warranty: | 1 Year |
| Marketing Type: | Ordinary Product | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Table Width: | 2300mm | T-slot (No./width/pitch): | 11/28/200mm |
| Cross Travel (Y): | 2700 (3050)mm | Vertical Travel (Z): | 1000mm |
| Gantry Width: | 2700mm | Max. Height Of Workpiece: | 1400mm |
| Distance From Spindle Nose To Table: | 280-1280mm | X/Y/Z-axis Rapid Feed Speed: | 6m/min |
| X/Y/Z-axis Feed Motor Torque: | 50N.m | Machine Weight: | 7750*5140*4100 |
| Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Energy & Mining, Advertising Company | Showroom Location: | Canada, France, Russia |
| Core Components: | Bearing | Port: | China Port |
Product Description
Product Description
Gantry type Machining Center
Specification
Specification | Unit | GMC2200 | GMC2700 |
Table width | mm | 2000 | 2300 |
T-slot (No./width/pitch) | mm | 9/22/200 | 11/28/200 |
Cross travel (Y) | mm | 2200 (2700) | 2700 (3050) |
Vertical travel (Z) | mm | 1000 | 1000 |
Gantry width | mm | 2300 | 2700 |
Max. height of workpiece | mm | 1400 | 1400 |
Accessories
Standard accessories:
▪ CNC controller: GSK
▪ Semi-Enclosed Splash Guard
▪ Work Lamp
▪ Alarm Lamp
▪ High Pressured Coolant & Air Gun
▪ Spindle Air Blast & Coolant Nozzle
▪ Rigid Tapping
▪ Auto Lubrication System
▪ USB & RS232
▪ Heat exchanger for electrical cabinet
▪ Editable CF Card Function
▪ Hand Wheel (MPG)
▪ Auto interrupt & Power Off System
▪ Chain Type Chip Conveyor + trolley
▪ Spindle oil cooler
▪ Leveling Blocks & Screws
▪ Tool & Tool Box
▪ Operation manual
▪ Semi-Enclosed Splash Guard
▪ Work Lamp
▪ Alarm Lamp
▪ High Pressured Coolant & Air Gun
▪ Spindle Air Blast & Coolant Nozzle
▪ Rigid Tapping
▪ Auto Lubrication System
▪ USB & RS232
▪ Heat exchanger for electrical cabinet
▪ Editable CF Card Function
▪ Hand Wheel (MPG)
▪ Auto interrupt & Power Off System
▪ Chain Type Chip Conveyor + trolley
▪ Spindle oil cooler
▪ Leveling Blocks & Screws
▪ Tool & Tool Box
▪ Operation manual
Optional accessories:
▪ FANUC 0i MF/ SIEMENS 828D
▪ Special milling head▪ Circular Coolant Nozzle
▪ Coolant through spindle (CTS)
▪ Spindle oil cooler
▪ Auto. Tool length measurement system
▪ Auto. Workpiece measurement systems
▪ Special milling head▪ Circular Coolant Nozzle
▪ Coolant through spindle (CTS)
▪ Spindle oil cooler
▪ Auto. Tool length measurement system
▪ Auto. Workpiece measurement systems
Packing & Delivery
This is the picture of the packaging in our factory！You can see our package is standardized and centralized , then they will be shipped to your designated place.
Positive Comments From Customers
This picture is the customer's favorable feedback to us. A picture can't mean anything, but we insist on the quality of the machine, we believe that repeat customers will be more and more.
Company Introduction
Since our company established, we have obtained many certificates. The above picture is for your reference. We will continue to provide excellent machine tools for domestic and foreign users.
Factory Display：
Text Introduction：
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
