High Precision VMC1690 CNC Vertical Machining Center with 24-Tool Magazine Capacity
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMEWAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $36,600.00/sets 1-2 sets |
|
Detail Information |
|||
| Condition: | New | Spindle Taper: | BT50 |
|---|---|---|---|
| No. Of Spindles: | 3 | Type: | VERTICAL |
| Weight (T): | 14.8 KG | Table Size (mm): | 1800x900 |
| CNC Control System: | FANUC | Table Travel (X) (mm): | 1600 |
| Table Travel (Y) (mm): | 900 | Table Travel (Z) (mm): | 680 |
| Positioning Accuracy (mm): | ±0.01 | Repeatability (X/Y/Z) (mm): | ±0.008 |
| Range Of Spindle Speed(r.p.m): | 0 - 6000 R.p.m | Max. Table Load(kg): | 1600 Kg |
| Feed Speed(mm/min): | 0 - 1500 Mm/min | Min. Time Of Tool Change(s): | 1 |
| Tool Magazine Capacity: | 24 | Key Selling Points: | Competitive Price |
| Warranty: | 1 Year | Marketing Type: | Hot Product 2024 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Machining Capacity: | Medium Duty |
| Spindle Bore(mm): | Other | Cutting Torque: | 125 N.m |
| Rapid Feed Speed(mm/min): | 0 - 1500 Mm/min | Machine Type: | CNC Vertical Machine Centers |
| Worktable Size (LxW): | 1800x900mm | Product Name: | 3-axis Vertical Cnc Machining Center |
| Loading Capacity: | 1600kg | Longitudinal Travel (X): | 1600mm |
| Cross Travel (Y): | 900mm | Vertical Travel (Z): | 680mm |
| Processing: | Metal Vertical Milling Machine | Color: | Custom-made |
| CNC Or Not: | CNC High Speed Machining Center | ||
Product Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Product Description
MAIN CONFIGURATION & ACCESSORIES:
1. Resin sand casting;
2. X, Y, Z rails are quenching - plastic sliding guide rail pair;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Standard with belt driven spindle, optional for direct driven spindle, gear head for all models;
5. Taiwan production pneumatic cylinder;
6. Taiwan ATC, carousel type and disc type are available as option;
7. Imported bearings for leadscrews;
8. Imported coupling;
9. Headstock balancing system have heavy casting or nitrogen balance system as option;
10. Full enclosure;
11. Rigid tapping;
12. Spindle center air blast;
13. Work lamp;
14. Pilot lamp;
15. USB and LAN interface;
16. Manual pulse generator (MPG);
17. Centralized automatic lubrication system.
18. Cooling system.
19. Heat exchanger for electrical cabinet ;
20. Leveling blocks & bolts;
21. Toolbox and tools;
22. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
2. X, Y, Z rails are quenching - plastic sliding guide rail pair;
3. X, Y, Z rails adopt stainless steel telescopic cover;
4. Standard with belt driven spindle, optional for direct driven spindle, gear head for all models;
5. Taiwan production pneumatic cylinder;
6. Taiwan ATC, carousel type and disc type are available as option;
7. Imported bearings for leadscrews;
8. Imported coupling;
9. Headstock balancing system have heavy casting or nitrogen balance system as option;
10. Full enclosure;
11. Rigid tapping;
12. Spindle center air blast;
13. Work lamp;
14. Pilot lamp;
15. USB and LAN interface;
16. Manual pulse generator (MPG);
17. Centralized automatic lubrication system.
18. Cooling system.
19. Heat exchanger for electrical cabinet ;
20. Leveling blocks & bolts;
21. Toolbox and tools;
22. CNC controller: KND,GSK, HNC (China); SIEMENS, FANUC, MITSUBISHI, FAGOR, etc.
OPTIONAL CONFIGURATION & ACCESSORIES:
1. The 4th axis wiring;
2. NC rotary table;
3. Direct driven spindle (Speed: 10000rpm, 12000rpm, 15000rpm);
4. Gearbox head (for all models)
5. Circular Coolant Nozzle;
6. Coolant through spindle (CTS);
7. Spindle oil cooler;
8. Air conditioner (A/C) for electrical cabinet;
9. Auto. Tool length measurement system;
10. Auto. Workpiece measurement systems;
11. Screw type chip conveyor;
12. Chain type chip conveyor;
13. High pressure water flush system;
14. Safety door;
15. Oil skimmer.
2. NC rotary table;
3. Direct driven spindle (Speed: 10000rpm, 12000rpm, 15000rpm);
4. Gearbox head (for all models)
5. Circular Coolant Nozzle;
6. Coolant through spindle (CTS);
7. Spindle oil cooler;
8. Air conditioner (A/C) for electrical cabinet;
9. Auto. Tool length measurement system;
10. Auto. Workpiece measurement systems;
11. Screw type chip conveyor;
12. Chain type chip conveyor;
13. High pressure water flush system;
14. Safety door;
15. Oil skimmer.
Specification
SPECIFICATION | UNIT | VMC1690 |
Worktable size (LxW) | mm | 1800×900 |
T-slot (No./width/pitch) | mm | 5-22-165 |
Loading capacity | kg | 1600 |
Longitudinal travel (X) | mm | 1600 |
Cross travel (Y) | mm | 900 |
Vertical travel (Z) | mm | 680 |
Distance from spindle nose to table | mm | 160-840 |
Distance from spindle center to column | mm | 950 |
Spindle taper | - | BT-50 (190) |
Spindle speed | rpm | 6000 |
X/Y/Z-axis rapid feed speed | m/min | 15/15/15 |
X/Y/Z-axis servo motor (FANUC) | - | β40/β40/β40 |
X/Y/Z-axis positioning accuracy | mm | ±0.01 |
X/Y/Z-axis repositioning accuracy | mm | ±0.008 |
Main motor power | kw | 18.5/22 |
Air pressure source | kg/cm2 | 6-8 |
Power capacity | Kva | 40 |
Tool magazine capacity | T | 24 (Disc) |
Guideway type | - | Sliding |
Machine weight | kg | 14800 |
Machine dimensions (LxWxH) | mm | 4290×3960×3440 |
