Universal High Precision Centerless Grinding Machine with Wheel Size of 350x150x120mm
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMEWAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $19,690.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Type: | Universal, Centerless Grinding Machine | CNC Or Not: | Normal |
|---|---|---|---|
| Condition: | New | Wheel Size(mm): | 350x150x120 |
| Year: | 2023 | Voltage: | Customized |
| Dimension(L*W*H): | 2350x1650x1770mm | Weight (KG): | 1700 |
| Power (kW): | 3 | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Showroom Location: | UAE, Viet Nam, Kenya, Australia, Japan, Spain, Egypt, Russia, Turkey, Peru, Chile |
| Applicable Industries: | Construction Works | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor |
| Grinding Wheel Size: | 350x150x120mm | Table Size Dia.: | 1-30mm |
| After-sales Service Provided: | Online Support | Application: | Metal Processing |
| Model: | CG-40S | Machine Type: | Manual |
| Max. Grinding Speed: | 1900rpm | COLOR: | Customized Optional |
| Packing Size: | 2350x1650x1770mm | Port: | China Port |
Product Description
Products Description
Specification | Unit | CG-40S |
Standard table size dia. | mm | 1-30 |
Standard table size dia. | mm | 25-40 |
Grinding wheel size | mm | 350x150x120 |
Regulating wheel size | mm | 205x150x90 |
Grinding wheel speed | rpm | 1900 |
Adjusting wheel speed | rpm | 10-300 |
Grinding drive motor | HP | 7.5 |
Grinding wheel drive motor | HP | 2 |
Table feed handwheel | mm/min | 0.001 |
Adjusting wheel feed hand wheel | mm/min | 0.02 |
Dresser feed handwheel | mm/min | 0.01 |
Machine weight | kg | 1700 |
Packing size (LxWxH) | mm | 2350x1650x1770 |
Why Choose Us
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
