Product Details:

Place of Origin: Henan, China
Brand Name: timeway

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: $150,000.00/sets 1-2 sets
Packaging Details: Wooden cases(can be fumigated)
Supply Ability: 150 Set/Sets per Month
Get Best Price Contact Now

Detail Information
CNC Or Not: Normal Condition: New
Grinding Length(mm): 6000 Surface Roughness(μm): 0 μm
Table Size(mm): 1250*6000 Table Travel (X) (mm): 1250
Table Travel (Y) (mm): 6000 Weight (KG): 18000
Power (kW): 22 Warranty: 1 Year
Key Selling Points: High Productivity Showroom Location: Spain, Turkey, Russia, Brazil, Saudi Arabia
Marketing Type: New Product 2020 Machinery Test Report: Provided
Video Outgoing-inspection: Provided Warranty Of Core Components: 1 Year
Core Components: Motor, Gearbox, Engine, Gear, Pressure Vessel Applicable Industries: Manufacturing Plant, Garment Shops, Construction Works , Printing Shops, Machinery Repair Shops
Product Name: Gantry Type Surface Grinder Machine Type: Suface Grinding Machine
Max. Grinding Length: 2000-8000mm Color: Cutomized
Model: DSG-1250A GRINDING WHEEL SIZE: 400*40*127mm
Spindle Motor: 22kw Max. Grinding Width: 1500mm
Worktable Size: 1250*2000-8000mm After-sales Service: 1 Year
Port: China Port

Product Description

Products Description
Normal CNC High Precision Gantry Surface Grinding Machine with 6000mm Table Travel 0
Normal CNC High Precision Gantry Surface Grinding Machine with 6000mm Table Travel 1
Features:
* The gantry surface grinder standard with a horizontal wheelhead, according to requirement, optional a vertical wheelhead.single saddle and double saddles, Double saddle can realize vertical grinding head and horizontal grinding head without interference grinding.
* This series of machine is a PLC gantry surface grinder with advanced technology of machine, electricity and liquid, which mainly serves the mechanical industry and mould industry, and is suitable for precise grinding of steel parts, cast iron and non-ferrous metals.
* The machine adopts the gantry type layout, which is composed of double column, beam and bed frame.
* Beam with 60° obliquebeam structure, mechanical performance is good, strong rigidity.
* The main spindle of grinding head adopts hydraulic-dynamic and static bush structure. It has the advantages of high motion accuracy, no wear, long life, small starting power, alrge bearing capacity and good vibration resistance.
* The working table is driven by oil cylinder, and can be stepless speed regulation, with mooth movement and low noise.
* Machine running reliable, cost-effective. Compact structure, small floor space and easy operation;
high raliability as a working machine.
* High rigidity box casting structure and thermal symmetrical deformation structure.
* High rigidity, high precision hydro-dynamic and hydro-static spindle.
* Large feed amount, high efficency.
* Hydraulic system temperature rise is small, low energy consumption.
* Rotating of vertical grinding head positioning with end gear plate 360° rotating table.
Specification
Specification
Unit
DSG-1250A
DSG-1600A
DSG-2000A
Table width
mm
1250
1600
2000
Table length
m
2/3/4/6/8
2/3/4/6/8
2/3/4/6/8
Gantry width
mm
1700
2200
2600
Max. grinding width
mm
1500
2000
2400
Max. grinding length
mm
2000-8000
2000-8000
2000-8000
Max. grinding height
mm
600/800/1000
600/800/1000
600/800/1000
Horizontal wheelhead intermittent feed rate
mm/str
3-30
3-30
3-30
Horizontal wheelhead feed of MPG
mm
0.005
0.005
0.005
Horizontal wheelhead motor power
kw
22
22
22
Horizontal grinding wheel size
mm
500x100x203
500x100x203
500x100x203
Horizontal spindle speed
rpm
1050
1050
1050
Vertical wheelhead swivel angle
°
±110°
±110°
±110°
Vertical wheelhead feed of MPG
mm
0.005
0.005
0.005
Vertical wheelhead motor power
kw
11/15
11/15
11/15
Vertical grinding wheel size
mm
400x40x127
400x40x127
400x40x127
Vertical spindle speed
rpm
1440
1440
1440
Accessories
Normal CNC High Precision Gantry Surface Grinding Machine with 6000mm Table Travel 2
        - LC+SMART auto. grinding controller
        - Coolant tank
        - Work lamp
        - Balancing arbor
        - Wheel flange and extractor
        - Wheel dresser stand
        - Y/Z axis electrical wheel(MPG)
        - Operation manual (English edition)
        - Splashing guard
        - Standard grinding wheel
        - Leveling wedge and boltd
        - Tools & tool-box
          - Operation manual(English edition)
      - Balancing stand
      - Magnetic separator
      - Paper filter
      - Oil tank guard
      - Electrical magnetic chuck
      - Built-in magnetic chuck controller
      - Parallel wheel dresser
      - 2 axis digital readout
      - Extra wheel flange
