Automatic High Precision Metal Lathe Machine for CNC or Normal Operations
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMAC |
| Certification: | CE & ISO |
| Model Number: | T-1640 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $7,500.00/sets 1-1 sets |
| Packaging Details: | in wooden case (can be fumigated) or plywood case |
| Supply Ability: | 50 Set/Sets per Month |
|
Detail Information |
|||
| Max. Length Of Workpiece (mm): | 1000 | Range Of Spindle Speed(r.p.m): | 25 - 2000 R.p.m |
|---|---|---|---|
| Machining Capacity: | Heavy Duty | Type: | Horizontal |
| Spindle Motor Power(kW): | 4 | Voltage: | As Customer's Request |
| Dimension(L*W*H): | 2170*1040*1340mm | Weight (KG): | 1670 KG |
| Warranty: | 1 Year | Key Selling Points: | Automatic |
| Marketing Type: | Ordinary Product | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| CNC Or Not: | Normal | Automatic Grade: | Manual |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Max. Swing Diameter: | 400mm |
| Local Service Location: | Germany | Machine Weight: | 1670kg |
| Spindle Bore: | 58mm | Brand: | Timeway |
| Condition: | New | Spindle Bore(mm): | 58 |
| Applicable Industries: | Garment Shops, Building Material Shops, Manufacturing Plant, Farms, Retail, Food Shop, Energy & Mining | Showroom Location: | Canada, United States, Italy, Germany |
| Core Components: | Bearing, Motor, Engine | Max. Turned Length (mm): | 1000 Mm |
| Port: | Chiana Port | ||
Product Description
Products Description
Feature:
1. The spindle system is high in rigidity and accuracy
2. There is no need for change gears.
3. The machine can turn about 200 kinds of metric, whitworth, module and D.P. threads.
4. An automatic stopping device is used to realize automatic stop for the machine of a certain length workpiece,which is safe and reliable.
5. A pedal braking device providing quick and effective stop while operating.
1. The spindle system is high in rigidity and accuracy
2. There is no need for change gears.
3. The machine can turn about 200 kinds of metric, whitworth, module and D.P. threads.
4. An automatic stopping device is used to realize automatic stop for the machine of a certain length workpiece,which is safe and reliable.
5. A pedal braking device providing quick and effective stop while operating.
Specification | T-1640 |
Max. length of workpiece | 1000mm(40") |
Max. Swing over bed | 400mm(16") |
Max. Swing over cross slide | 224mm(8-13/16") |
Max. Swing over gap | 640mm(25-1/8") |
Spindle nose | D1-6 |
Diameter /taper of spindle bore | 58mm(2-1/4"), NO.6Morse |
Range of spindle speed | 12 steps, 25-2000r/min |
Max. Travel of compound rest | 120mm (4-3/4") |
Max. Travel of cross slide | 290mm (11-3/8") |
Max. Section of tool | 25mm×25mm (1×1") |
Longitudinal feeds range | 42 kinds 0.031-1.7 mm/rev |
Cross feeds range | 42 kinds 0.014-0.784 mm/rev |
Metric threads range | 41 kinds, 0.1-14mm |
Inch threads range | 60 kinds, 2-112T.P.I. |
Diametrical pitches range | 50 kinds, 4-112D.P. |
Module pitches range | 34 kinds, 0.1-7M.P. |
Diameter /taper of tailstock sleeve | 60mm(2-5/16"), NO.4Morse |
Travel of tailstock sleeve | 120mm(4-3/4") |
Power of main motor / coolant pump | 4kw(5.4HP), 0.1kw(1/8HP).3PH |
Net weight / gross weight | 1670/1980kg |
Overall dimension (L×W×H) | 2170×1040×1340mm |
Packing size (L×W×H) | 2250×1120×1700mm |
3-Jaw Chuck 4-Jaw Chuck Steady Rest Follow Rest Face Plate Dead Centers Chasing Dial Indicator Work Light Change Gears Set Reduction Sleeve Coolant System Full LengthSplash Guard Brake System ToolBox & Tools | Leadscrew Guard Drill Chuck+Arbor Taper Turning Attachment Digital Readout (2 Axis) Quick Change Tool Post Live Center, Chuck Guard |
