Horizontal Combination of Lathe Mill and Drill Max. Travel of Tailstock Quill 110mm
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMAC |
| Certification: | CE ISO |
| Model Number: | TM-1236A TM-1240A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $20,000.00/sets 1-4 sets |
| Packaging Details: | wooden case / plywood case |
| Supply Ability: | 500 Set/Sets per Month |
|
Detail Information |
|||
| Max. Length Of Workpiece (mm): | 910 | Range Of Spindle Speed(r.p.m): | 65 - 1400 R.p.m |
|---|---|---|---|
| Machining Capacity: | Heavy Duty | Type: | Horizontal |
| Voltage: | 220/380V | Dimension(L*W*H): | As Model |
| Weight (KG): | 560 KG | Warranty: | 1 Year |
| Key Selling Points: | Energy Saving | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | CNC Or Not: | Normal |
| Automatic Grade: | Manual | After-sales Service Provided: | Online Support |
| Multi-Purpose Machine: | Lathe, Milling, Drilling | Max. Swing Diameter: | 300mm |
| Power: | 1.1kw | Max. Travel Of Tailstock Quill: | 110mm |
| Taper Of Tailstock Bore: | MT3 | Main Motor Power: | 1.1/1.5 |
| Condition: | New | Spindle Bore(mm): | 38 |
| Applicable Industries: | Manufacturing Plant | Showroom Location: | France, Viet Nam, Indonesia, Russia, Kenya, Colombia, Bangladesh, Australia |
| Core Components: | Gearbox, PLC | Max. Turned Length (mm): | 910 Mm |
| Port: | China Port | ||
Product Description
Products Description
Specification | Unit | TM1236A | TM1240A |
Max. swing over bed | mm | 300 | 300 |
Max. swing over cross slide | mm | Φ180 | Φ180 |
Max. swing over gap | mm | 430 | 430 |
Distance between centers | mm | 910 | 1000 |
Spindle bore | mm | Φ38 | Φ38 |
Taper of spindle bore | - | MT5 | MT5 |
Range of spindle speed | rpm | 65-1400 (or 65-1810) | 65-1400 (or 65-1810) |
Range of longitudinal feeds | mm/r | 0.079-1.291 | 0.079-1.291 |
Range of cross feeds | mm/r | 0.017-0.276 | 0.017-0.276 |
Range of metric threads | mm | 0.4-7 | 0.4-7 |
Range of inch threads | TPI | 4-60 | 4-60 |
Max. travel of tailstock quill | mm | 100 | 100 |
Taper of tailstock bore | - | MT3 | MT3 |
Main motor power | kw | 1.1/1.5 | 1.1/1.5 |
Max. drilling capacity | mm | 25 | 25 |
Max. distance from bench to spindle nose | mm | 232 | 232 |
Drilling spindle speed steps | - | Variable speed | Variable speed |
Drilling spindle speed range | rpm | 100-1000 | 100-1000 |
Size of worktable | mm | 340x120 | 340x120 |
Max. travel of drilling spindle quill | mm | 80 | 80 |
Max. end milling capacity | mm | 25 | 25 |
Max. face milling capacity | mm | 50 | 50 |
Head stock stroke (Z) | mm | 230 | 230 |
Drilling motor power | kw | 0.6 | 0.6 |
Net weight | kg | 130 | 130 |
Asunder packing of millhead | mm | 1060x630x740 | 1060x630x740 |
Unitary packing of mill combo | mm | 1680x850x1850 | 1940x850x1850 |
Unitary packing of lathe | mm | 1680x750x1400 | 1850x750x1400 |
Asunder packing of lathe | mm | 1680x750x740 (700x460x380/300) | 1850x750x740 (700x460x380/300) |
Net weight | kg | 540 | 620 |
Standard accessories
Three jaw chuck,
Centers,
Thread chasing dial,
Splash guard,
Toolbox & tools 1 set
Special accessories
Coolant system,
Brake, Driving plate,
Living center,
Taper turning attachment,
Drill chuck,
Stopper,
QCTP,
DRO,
Chuck cover,
Leadscrew cover,
Leadscrew cover,
Tool post cover,
Face plate.
Why Choose Us
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
