AL-1000B Heavy Duty Horizontal Lathe Standard Year 2023 for Manual Lathe Performance
Product Details:
| Place of Origin: | China |
| Brand Name: | Timeway |
| Model Number: | AL-1000B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $40,000.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Max. Length Of Workpiece (mm): | 3000 | Range Of Spindle Speed(r.p.m): | 3.15 - 315 R.p.m |
|---|---|---|---|
| Machining Capacity: | Heavy Duty | Type: | Horizontal |
| Spindle Motor Power(kW): | 22 | Voltage: | As Customer Requirement |
| Dimension(L*W*H): | 4600x2150x1700mm | Weight (KG): | 20500 KG |
| Warranty: | 1 Year | Key Selling Points: | High Productivity |
| Marketing Type: | Ordinary Product | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Name: | Universal Lathe Machine | Machine Type: | Horizontal Metal Turning Lathe Machine |
| After-sales Service Provided: | Online Support | Keyword: | Metal Turning Lathe |
| Function: | Metal Turning | CNC Or Not: | Nomal |
| Processing: | Metal Working Lathe Machine | Distance Between Centers: | 1500/2000/3000/4000/5000/6000/8000/10000/12000mm |
| Spindle Hole: | 130mm | Color: | Standard |
| Condition: | New | Showroom Location: | Turkey, United Kingdom, United States, Italy, France, Brazil, India, Russia, Spain, Japan, Australia |
| Core Components: | Bearing, Gear, Motor, Gearbox | Spindle Bore(mm): | 130mm |
| Max. Turned Length (mm): | 3000 Mm | Year: | 2023 |
| Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Other | Port: | China Port |
Product Description
Products Description
Specification | Unit | AL-1000B |
Max. swing over bed | mm | 1000 |
Max. swing over cross slide | mm | 615 |
Distance between centers | mm | 1500/2000/3000/4000/5000/6000/8000/10000/12000 |
Max. turning length | mm | 1300/1800/2800/3800/4800/5800/7800/9800/11800 |
Bed width | mm | 755 |
Loading capacity | kg | 6000 |
Spindle nose | - | A2-15 (8xM22) |
Spindle bore | mm | 130 |
Spindle taper | - | Metric 140 |
Spindle speed range | rpm | CCW: 3.15-315, CW: 3.5-291 |
Spindle speed step | steps | CCW: 21, CW: 12 |
X/Z-axis feed kinds | kinds | 56/56 |
Feed range | mm | Longitudinal: 0.1-12; Cross: 0.05-6; Top tool-post: 0.025-3 |
Metric threads range (kinds) | mm | 1-120 (44) |
Inch threads range (kinds) | TPI | 28-1/4 (31) |
Module threads range (kinds) | MP | 0.5-60 (45) |
Diametrical threads range (kinds) | DP | 1/2-56 (38) |
Distance spindle center to tool base | mm | 48 |
Tool post swivel angle | ° | ±90° |
Cross slide travel | mm | 520 |
Top slide travel | mm | 300 |
Tool section size | mm | 45x45 |
Rapid feed speed | mm/min | Longitudinal: 3740; Cross: 1870; Top tool-post: 935 |
Tailstock quill diameter | mm | 160 |
Tailstock quill travel | mm | 300 |
Tailstock quill taper | - | MT6 |
Main motor power | kw | 22 |
Machine length | mm | 4600/5100/6100/7100/8100/9100/11100/13100/15100 |
Machine width | mm | 2150 |
Machine height | mm | 1700 |
·4-jaw independent chuck ·Steady rest (over 3M length) ·Follow rest ·Manual moving tailstock ·Dead center ·4-station tool post ·Cooling system ·Work lamp ·Tools & tool-box ·Leveling wedge and bolts ·Operation manual (English) | ·2 or 3-axis DRO ·Chuck guard ·Tool-post guard ·Rear splash guard ·Electric moving tailstock ·Grinding attachment. |
