Max. Length 2000mm Mental Gap Bed Lathe Machine Perfect for Various Workpiece Sizes
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMAC |
| Model Number: | BL-660 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $12,310.00/sets 1-2 sets |
| Packaging Details: | wooden case |
| Supply Ability: | 10 Set/Sets per Month |
|
Detail Information |
|||
| Max. Length Of Workpiece (mm): | 1000 | Range Of Spindle Speed(r.p.m): | 36 - 1600 R.p.m |
|---|---|---|---|
| Machining Capacity: | Medium Duty | Width Of Bed (mm): | 80 |
| Type: | Horizontal | Spindle Motor Power(kW): | 7.5 |
| Voltage: | Customized | Dimension(L*W*H): | 3632x975x1450mm |
| Weight (KG): | 2600 KG | Warranty: | 1 Year |
| Key Selling Points: | High Productivity | Marketing Type: | New Product 2020 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | CNC Or Not: | Normal |
| Horizontal Lathe: | Medium Duty Horizonal Gap Bed Lathe | Swing Over Bed: | 660mm |
| Swing Over Cross Slide: | 420mm | Max. Length Of Workpiece: | 2000mm |
| Max. Turning Length: | 1950mm | Taper Hole Of Spindle: | ISO702 |
| Machine Type: | Metal Turning Lathe Machine | After-sales Service Provided: | 1 Year (no Human-made Reason) |
| Color: | Customrized | Condition: | New |
| Spindle Bore(mm): | 105 | Showroom Location: | Canada, United Kingdom, United States, Philippines, Brazil, Pakistan, Mexico, Russia, Spain, Kenya, Chile, UAE, Ukraine, Australia |
| Max. Turned Length (mm): | 1950 Mm | Year: | 2023 |
| Applicable Industries: | Construction Works , Other | Core Components: | Motor, Other |
Product Description
Products Description
Specification | Unit | BL-500C | BL-660C |
Max. swing over bed | mm | 500 | 660 |
Max. swing over cross slide | mm | 300 | 420 |
Max. swing over gap | mm | 710 | 870 |
Gap length | mm | 240 | 240 |
Distance between centers | mm | 750/1000/1500/2000/3000 | 750/1000/1500/2000/3000 |
Max. turning length | mm | 700/950/1450/1950/2950 | 700/950/1450/1950/2950 |
Spindle bore | mm | Φ105 | Φ105 |
Spindle taper | - | Φ113, 1:20 | Φ113, 1:20 |
Spindle nose | - | ISO 702/II No.8 | ISO 702/II No.8 |
Spindle speed range (steps) | rpm | 36-1600 (12) | 36-1600 (12) |
Top slide travel | mm | 145 | 145 |
Cross slide travel | mm | 320 | 310 |
Tool section size | mm | 25x25 | 25x25 |
X-axis rapid feed speed | m/min | 50HZ: 1.9; 60HZ: 2.3 | 50HZ: 1.9; 60HZ: 2.3 |
Z-axis rapid feed speed | m/min | 50HZ: 4.5; 60HZ: 5.4 | 50HZ:4.5; 60HZ: 5.4 |
X-axis feed range | mm/r | 0.027-1.07 (65) | 0.027-1.07 (65) |
Z-axis feed range | mm/r | 0.63-2.52 (65) | 0.63-2.52 (65) |
Metric threads range (kinds) | mm | 1-14 (22) | 1-14 (22) |
Inch threads range (kinds) | TPI | 28-2 (25) | 28-2 (25) |
Module threads range (kinds) | MP | 0.5-7 (18) | 0.5-7 (18) |
Diametrical threads range (kinds) | DP | 56-4 (24) | 56-4 (24) |
Tailstock quill diameter | mm | Φ75 | Φ75 |
Tailstock quill travel | mm | 150 | 150 |
Tailstock quill taper | - | MT5 | MT5 |
Main motor power | kw | 7.5 | 7.5 |
Rapid feed motor power | kw | 0.3 | 0.3 |
Coolant pump motor power | kw | 0.12 | 0.12 |
Machine length | mm | 2382/2632/3132/3632/4632 | 2382/2632/3132/3632/4632 |
Machine width | mm | 975 | 975 |
Machine height | mm | 1270 | 1450 |
Machine weight | kg | 2050/2100/2300/2500/2900 | 2150/2200/2400/2600/3000 |
· 3-jaw chuck · 4-jaw chuck · Face plate · Thread chasing dial · Splash guard Oil gun · Steady rest · Follow rest · Dead center · Cooling system · Work lamp · Change gears · Reducing sleeve Foot brake · Tools & tool-box · Leveling wedge and bolts · Operation manual (English) | · 2 or 3-axis DRO · Chuck guard · Quick change tool post · Living center · Taper turning attachment · Leadscrew guard · Tool post guard |
