80mm Max. Drilling Dia. Metal Processing Machine RD825 with 15000/11000kg Capacity
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMAC |
| Certification: | ISO9001; CE |
| Model Number: | RD825 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $12,000.00/sets 1-2 sets |
| Packaging Details: | Veneer box or wooden case |
| Supply Ability: | 65 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Type: | Radial Drilling Machine |
|---|---|---|---|
| Max. Drilling Dia. (mm): | 80 | Range Of Spindle Speed(r.p.m): | 16 - 1250 R.p.m |
| CNC Or Not: | Normal | Drilling Speed: | 16-1250 R.p.m |
| Voltage: | As Customer's Request | Power (kW): | 7.5 |
| Weight (KG): | 11000 KG | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Showroom Location: | United States, Italy, France, Brazil, Saudi Arabia, South Africa, Uzbekistan |
| Applicable Industries: | Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Construction Works , Energy & Mining | Marketing Type: | New Product 2020 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Bearing, Pump, Gear, Motor |
| Drilling Machine: | Machine Tools | Power: | 7.5 |
| Weight: | 15000/11000kg | Port: | China Port |
Product Description
80mm Drilling / Radial Drilling Machine For Metal Processing / RD825
Feature:
Radial Drilling Machine For Metal Processing
1. The radial drilling machine is new series with diversified fuctions of product which has been designed and accomplished referring to international standard ISO in the recent years.
2. In this machine, hydraulic preselection speed and feed change mechanisms are adopted, the spindle head, radial arm and column are clamped by hydraulic clamping mechanisms.
3. The forward, reverse, stop(braking), as well as the setting of spindle in neutral position are all controlled by a single lever, the machine has characteristics features of perfect performance, safe, reliable and easy operation, convenient maintenance, high-accuracy, ample rigidity and long service long.
4. It is used for drilling, counter boring, spot facing, reaming, tapping and boring, widely used in every department of mechaninal machining.
Parameter:
| Specification | RD620 | RD825 |
| Max.Drilling capacity (mm) | 63 | 80 |
| Distance spindle axis to column generating line (mm) | 450-2050 | 500-2500 |
| Diameter of column (mm) | 450 | 550 |
| Spindle taper | MT5 | MT6 |
| Spindle travel (mm) | 400 | 450 |
| Spindle speeds range (r/min) | 20-1600 | 16-1250 |
| Spindle speeds steps | 16 | 16 |
| Range of Spindle feeds (mm/r) | 0.04-3.2 | 0.04-3.2 |
| Spindle feeds steps | 16 | 16 |
| Max.Distance spindle nose to working surface of base (mm) | 400-1600 | 550-2000 |
| Dimension of worktable (mm) | 960×630×500 | 1000×800×560 |
| Dimension of base (mm) | 2900×1250×250 | 3530×1400×300 |
| Overall Size (mm) | 3110×1250×3150 | 3730×1400×3790 |
| Power of Main motor (KW) | 5.5 | 7.5 |
| G.W/N.W (kg) | 8000/7000 | 15000/11000 |
| Packing dimension (cm) | 347×147×235 | 416×165×248 & 382×163×170 |
