210 KG Gear Head Borehole Drilling Machine for Machinery Repair Shops Performance
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMAC |
| Model Number: | Z-25A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $1,998.00/sets >=2 sets |
| Packaging Details: | Wooden package |
| Supply Ability: | 100 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Type: | Column Drilling Machine |
|---|---|---|---|
| Max. Drilling Dia. (mm): | 25 | Range Of Spindle Speed(r.p.m): | 105 - 2900 R.p.m |
| CNC Or Not: | Normal | Voltage: | 220 V |
| Dimension(L*W*H): | 580X730X1820 Mm | Power (kW): | 0.9 Kw |
| Weight (KG): | 210 KG | Warranty: | 1 Year |
| Key Selling Points: | Easy To Operate | Showroom Location: | Philippines, Brazil, Peru, Indonesia, India, Mexico, Russia, Thailand, Chile, Colombia, South Africa |
| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Other | Marketing Type: | Hot Product 2019 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Other |
| Max. Drilling Diameter: | 25 Mm | Machine Type: | Drilling Machine |
| Warranty Period: | 1 Year | Tapping Capacity: | M16 |
| Quill Movement: | 135 | Morse Taper: | MT3 |
| Motor Power(50HZ): | 0.65 Kw/0. 9kw | Motor Power(60HZ): | 0.8 Kw/1.1 Kw |
| Net/Gross Weight: | 210 Kg/257 Kg | Packing Size: | 580x730x1820 Mm |
Product Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Products Description
Built-in motor, fast speed up to 2900 rpm; Low noise, main engine engages with bamboo gears, suitable for drilling small-bore workpieces; High precision, compact design appearance, with protective power-off function, safe and reliable.
Specification | Z-25A |
Max. travel of spindle | 135 mm |
Max. drilling capacity | 25 mm |
Max. tapping capacity | M16 |
Morse taper | MT3 |
Max.distance from spindle nose to working surface of work table | 940 mm |
Max.distance from spindle nose to working surface of base plate | 1250 mm |
Up and down movement distance of spindle box | 460 mm |
Effective working area of table(L×W) | 500×360 mm |
Effective working area of base plate(L×W) | 490×400 mm |
Motor power(50HZ) | 0.65 kw/0.9 kw |
Motor power(60HZ) | 0.8 kw/1.1 kw |
Feed speed | 0.1-0.15-0.33 mm/rev |
Net/Gross weight | 210 kg/257 kg |
Packing size | 580×730×1820 mm |
Drill chuck Arbor Taper sleeve Drift Eyelet bolts Wrench | Multi-spindles Angle vice Safety guard |
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Factory Display：
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
Want to Know more details about this product
