160kN Ejector Force Hydraulic Press Machine for Customized Production Needs
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMEWAY |
| Model Number: | J23-16; J23-25;J23-40; |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $8,650.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Slide Stroke (mm): | 70 | Machine Type: | Single Column Hydraulic Press, Hydraulic Press |
|---|---|---|---|
| Ejector Force (kN): | 160 | Return Force (kN): | 160 KN |
| System: | Normal | Condition: | New |
| Year: | 2023 | Voltage: | CUSTOMIZED |
| Dimension(L*W*H): | 1140x900x1890 | Weight (T): | 1.07 T |
| Motor Power (kw): | 1.5 Kw | Key Selling Points: | High-accuracy |
| Warranty: | 1 Year, 1-year | Applicable Industries: | Machinery Repair Shops, Other |
| Showroom Location: | Egypt, United States, Italy, Philippines, Brazil, Peru, Indonesia, Russia, Spain, Thailand, South Korea, Chile, UAE, Japan, Australia | Marketing Type: | Hot Product 2019 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Other |
| After-sales Service Provided: | One Year | Color: | Customer Requirements |
| Power: | 1.5kw | Product Name: | Hydraulic Press Machine |
| Type: | Hydraulic Bending Tools | Material: | Steel Material |
| Power Supply: | 380V 50Hz 3 Phase | Quality: | Excellent |
| Port: | China Port | ||
Product Description
Products Description
Specification | Unit | J23-16 | J23-25 | J23-40 |
Nominal force | KN | 160 | 250 | 400 |
Stoke of nominal force | mm | 3 | 3 | 5 |
Stroke of sliding block | mm | 70 | 65 | 100 |
Max. indined angle of machine body | ° | 30° | 30° | 30° |
Max. height for die loading | mm | 160 | 200 | 220 |
Adjustment range fro die loading height | mm | 60 | 70 | 80 |
Distance from slide block centre to the frame | mm | 160 | 190 | 240 |
Space between columns | mm | 220 | 250 | 300 |
Bottom surface size of sliding block | mm | 180x200 | 210x250 | 270x320 |
Die handle hole size | mm | 40x60 | 40x60 | 50x70 |
Main motor power | kw | 1.5 | 2.2 | 4 |
Machine dimension(LxWxH) | mm | 1140x900x1890 | 1350x950 x2200 | 1500x1200 x2300 |
Worktable size | mm | 300x450 | 360x560 | 460x700 |
Machine weight | kg | 1070 | 1800 | 3250 |
Why Choose Us
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
Want to Know more details about this product
