Upgrade Your Cutting Process with 2900KG High Speed EDM Wire Cut DK-ZF Series Release
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMAC TIMEWAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $19,000.00/sets 1-2 sets |
| Packaging Details: | Wooden caces ( can be fumigated) |
| Supply Ability: | 60 Set/Sets per Month |
|
Detail Information |
|||
| CNC Or Not: | CNC | Condition: | New |
|---|---|---|---|
| Machine Type: | Wire EDM | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 1 Year | Core Components: | Engine, Motor |
| Weight (KG): | 2900 | Power (kW): | 2.2 |
| Warranty: | 1 Year | Key Selling Points: | Multifunctional |
| Applicable Industries: | Food & Beverage Shops, Garment Shops, Machinery Repair Shops, Food Shop, Hotels, Energy & Mining | Showroom Location: | Canada, United States, Italy, Germany |
| Taper (optional): | 0° /6° /30° /60° | Precision: | ≤0.015mm |
| Load Of Table: | 300kg | Cutting Depth (optional): | 300/500mm |
| Work Table Travel: | 250x320mm | Work Table Size: | 380x525mm |
| Motor Type: | X/Y/U/V-axis: Stepper Motor Drive | Axis Controlled: | 4-axis Linkage |
| Min. Feed Unit: | 0.001mm | Power Supply: | 3PH-380V/50Hz |
| Port: | FOB China | ||
Product Description
Products Description
EDM Wire Cut
Features:
The castings are cast in resin sand and tempered twice to effectively control the deformation of the machine.
The double-nut ball screw produced by domestic military enterprises is used to maintain mechanical precision for a long time.
The wire storage tube adopts frequency conversion speed regulation, and the electric wire is tightly tightened for convenient operation.
Standard stepper motor, optional two-axis or four-axis hybrid subdivision motor.
With cut-repair-function.
There are two types of electric cabinets for the cabinet and the vertical cabinet (only one cabinet controlled by the single board machine).
The castings are cast in resin sand and tempered twice to effectively control the deformation of the machine.
The double-nut ball screw produced by domestic military enterprises is used to maintain mechanical precision for a long time.
The wire storage tube adopts frequency conversion speed regulation, and the electric wire is tightly tightened for convenient operation.
Standard stepper motor, optional two-axis or four-axis hybrid subdivision motor.
With cut-repair-function.
There are two types of electric cabinets for the cabinet and the vertical cabinet (only one cabinet controlled by the single board machine).
Specification | Unit | DK-250ZF | DK-320ZF | DK-400ZF | ||
Table size (WxL) | mm | 400×580 | 440×680 | 540×760 | ||
Table travel (X/Y) | mm | 250×320 | 320×400 | 400×500 | ||
U/V-axis travel | mm | 70×70 | 70×70 | 70×70 | ||
Loading capacity | kg | 400 | 600 | 1000 | ||
Max. thickness of workpiece | mm | 400 | 400 | 400 | ||
Taper angle/thickness | ° | ±5°/60 | ||||
Z-axis lifting type | - | motorized lifting | ||||
Guideway type | - | steel rolling guide | ||||
Wire cylinder travel | mm | 200 | ||||
Molybdenum wire diameter | mm | φ0.15～φ0.20 (recommend φ0.18) | ||||
Wire feed speed | m/s | 1～11.4, 2steps (stepless) | ||||
Working accuracy | mm | ≤0.012 | ||||
Max. machining speed | mm2/min | ≥250 | ||||
Surface roughness | μm | One: Ra≤2.5, Two: Ra≤1.8 | ||||
Motor type | - | X/Y/U/V-axis: stepper motor drive | ||||
Axis controlled | - | 4-axis linkage | ||||
Min. feed unit | mm | 0.001 | ||||
Power supply | - | 3PH-380V/50Hz | ||||
Max. working current | A | 9 | ||||
Total power | kw | 2.2(stepper); 6(mixing） | ||||
Working liquid | - | DIC | ||||
Tank capacity | L | 55 | ||||
Filtering type | - | filter screen | ||||
Machine noise | db | ≤70 | ||||
Machine weight | kg | 1250 | 1480 | 1730 | ||
Machine dimensions(LxWxH) | cm | 142×104×190 | 155×117×190 | 180×138×190 | ||
Packing size (LxWxH) | cm | 172x130x205 | 172x130x205 | 195x150x205 | ||
Specification | Unit | DK-500ZF | DK-630ZF | DK-800ZF | DK-1000ZF | |||
Table size (WxL) | mm | 640×1020 | 750×1140 | 950x1440 | 1140x1640 | |||
Table travel (X/Y) | mm | 500×630 | 630×800 | 800x1000 | 1000x1200 | |||
U/V-axis travel | mm | 70×70 | 70×70 | 70×70 | 70×70 | |||
Loading capacity | kg | 1600 | 2400 | 3200 | 4000 | |||
Max. thickness of workpiece | mm | 450 | 550 | 700 | 800 | |||
Z-axis lifting type | - | motorized lifting | ||||||
Guideway type | - | steel rolling guide | ||||||
Wire cylinder travel | mm | 200 | ||||||
Molybdenum wire diameter | mm | φ0.15～φ0.20 (recommend φ0.18) | ||||||
Wire feed speed | m/s | 1～11.4, 2steps (stepless) | ||||||
Working accuracy | mm | ≤0.012 | ||||||
Max. machining speed | mm2/min | ≥250 | ||||||
Surface roughness | μm | One: Ra≤2.5, Two: Ra≤1.8 | ||||||
Motor type | - | X/Y/U/V-axis: stepper motor drive | ||||||
Axis controlled | - | 4-axis linkage | ||||||
Min. feed unit | mm | 0.001 | ||||||
Power supply | - | 3PH-380V/50Hz | ||||||
Max. working current | A | 9 | ||||||
Total power | kw | 2.2(stepper); 6(mixing） | ||||||
Working liquid | - | DIC | ||||||
Tank capacity | L | 55 | ||||||
Filtering type | - | filter screen | ||||||
Machine noise | db | ≤70 | ||||||
Machine weight | kg | 2500 | 2900 | 5400 | 6000 | |||
Machine dimensions (LxWxH) | cm | 206×176×205 | 225×225×215 | 318x328x248 | 330x327x230 | |||
Packing size (LxWxH) | cm | 212x172x210 | 225x172x225 | - | - | |||
