High Speed Wire Cutting EDM Machine with Cabinet Computer Workbench size 750*1140mm
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMEWAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $25,467.00/sets 1-2 sets |
| Packaging Details: | By wooden case |
|
Detail Information |
|||
| CNC Or Not: | Normal | Condition: | New |
|---|---|---|---|
| Machine Type: | Wire EDM | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Hot Product 2019 |
| Warranty Of Core Components: | 1 Year | Core Components: | Engine, Motor |
| Year: | 2023 | Voltage: | 380V/220V |
| Dimension(L*W*H): | 2250X2250X1950mm | Weight (KG): | 2700 |
| Power (kW): | 2.2 | Warranty: | 1 Year |
| Key Selling Points: | Long Service Life | Applicable Industries: | Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Retail, Energy & Mining, Construction Works |
| Showroom Location: | Turkey, United Kingdom, United States, France, Philippines, Brazil, Peru, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, South Korea, Chile, UAE, South Africa, Kazakhstan, Ukraine, Uzbekistan, Australia | Product Name: | EDM Wire Cutting Machine |
| Controlling Mode: | CNC Control | Application: | Multi-purpose |
| Color: | Customization | Workbench Size: | 750*1140mm |
| Axis Control: | 4-axis Linkage | Brand: | Timeway |
| Model: | DK-400Z, DK-630Z, | Material: | Steel |
Product Description
Products Description
Specification | Unit | DK-400Z | DK-630Z |
Table size(WxL) | mm | 540x760 | 750x1140 |
Table travel(X/Y) | mm | 400x500 | 630x800 |
U/V-axis travel | mm | 70x70 | 70x70 |
Loading capacity | kg | 1000 | 2400 |
Max. thickness of workpiece | mm | 400 | 550 |
Taper angle | mm | 5°/60 | 5°/60 |
Wire feed speed | m/s | 1-11.4, 2 stpes | 1-11.4, 2 stpes |
Working accuracy | mm | 0.012 | 5-18-100 |
Max. machining speed | mm2/min | 250 | 250 |
Motor type | kg | stepper motor driver | stepper motor driver |
Axis controlled | kg/m | 4-axis linkage | 4-axis linkage |
Power supply | - | 380V/50HZ/3PH | 380V/50HZ/3PH |
Total power | mm | 2.2 | 2.2 |
Tank capacity | - | 55 | 55 |
Machine weight | kg | 1600 | 2700 |
Machine dimensions (LxWxH) | mm | 1950x1500x1800 | 2250x1720×2050 |
