720KG One Piece Air Forging Hammer/Metal Forging Air Hammer Machine with Competitive
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMAC TIMEWAY |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $5,000.00/sets 3-4 sets |
| Packaging Details: | Wooden case(can be fumigated) |
| Supply Ability: | 500 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Machine Type: | Air Hammer |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Hot Product 2019 | Warranty Of Core Components: | 1 Year |
| Core Components: | Engine, Motor, Pump | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Showroom Location: | France, Brazil, Saudi Arabia |
| Applicable Industries: | Manufacturing Plant | Weight (KG): | 720 |
| Air Hammer: | Air Hammer | After-sales Service Provided: | Online Support |
| After Warranty Service: | Video Technical Support | Local Service Location: | France |
| Overall Dimension: | 700X450X980 | Weight Anvil Block: | 420 |
| Name: | Forging Hammer | Port: | China Port |
Product Description
Products Description
pneumatic forging hammer
This pneumatic forging hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forge, welding, bending and twisting. It is also used for forging in bolster dies.
This pneumatic forging hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forge, welding, bending and twisting. It is also used for forging in bolster dies.
Feature
1. Ready operation is economic and convenient.
2. Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions - idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired.
3. A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.
2. Easy to operate, by manipulating the hand lever or foot-pedal, all operating functions - idle run, top setting, pressing down, single blow, light or full series blow can be obtained as desired.
3. A special oil-pump is provided for lubricating the cylinders. Prior to running, turn the hand-crank of the pump to get the cylinders being lubricated beforehand.
Specification | Unit | C41-15 | C41-25 | C41-40 | C41-55 |
Weight of falling parts | kg | 15 | 25 | 40 | 55 |
Max. hit energy | kj | 0.16 | 0.27 | 0.53 | 0.7 |
Hit number | min-1 | 245 | 250 | 245 | 230 |
Height of working area | mm | 160 | 240 | 245 | 270 |
Tup axis to frame front | mm | 140 | 200 | 235 | 270 |
Forges Square | mm x mm | 30x30 | 40x40 | 52x52 | 60x60 |
Forges Round | mm | Φ35 | Φ48 | Φ68 | Φ75 |
Motor power | kw | 2.2 | 3 | 4 | 5.5 |
Weight Hammer | kg | 270 | 720 | 710 | 1150 |
Weight Anvil block | kg | - | - | 420 | 600 |
Overall Dimension | mm | 700x450x980 | 1100x500x1300 | 1200x600x1500 | 1300x700x1600 |
