Product Details:

Place of Origin: China
Brand Name: TIMAC
Certification: CE norms; ISO9001
Model Number: M250

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: $8,500.00/sets 1-2 sets
Packaging Details: Wood case(can be fumigated)
Supply Ability: 50 Set/Sets per Month
Get Best Price Contact Now

Detail Information
Table Travel (X) (mm): 950 Machining Capacity: Light Duty
Table Travel (Y) (mm): 420 Table Travel (Z) (mm): 420
Spindle Taper: ISO40 Range Of Spindle Speed(r.p.m): 80 - 5440 R.p.m
Type: VERTICAL Spindle Motor Power(kW): 3.75
Voltage: As Customer Request Dimension(L*W*H): 1516 X 1550 X 2080mm
Weight (KG): 1550 Warranty: 1 Year After Delivery
Key Selling Points: Easy To Operate Marketing Type: Ordinary Product
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year CNC Or Not: Normal
Milling Machine: Machine Tools Power: 3.75kw
Weight: 1550 Number Of Axes: 2
Condition: New Applicable Industries: Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Construction Works , Energy & Mining
Showroom Location: Algeria, South Africa, Ukraine, Uzbekistan, Turkey, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico Core Components: Bearing, Motor, Pump, Gear, Engine
Table Travel (mm): 950x420x420mm Year: 2022
Port: China Port

Product Description

Vertical Turret Milling Machine



M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 0

M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 1

M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 2



M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 3



M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 4M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 5M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 6M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 7M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 8M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 9



M250 Turret Milling Machine with 254x1370 mm Table Size and 3.75kW Spindle Motor Power 10





Vertical Turret Milling Machine



Model Unit M230A M230B M250 M250A M250B M250U M250C M250D M300 M300A M330 M330A
Table size mm 230x1067 254x1270 250x1270 254x1270 305x1370 330x1370
230x1246 254x1370 254x1370 305x1500 330x1500
Longitudianl travel mm 650 / 840 850 / 950 770 850 / 950 870 / 1000 840 / 1000
Cross travel mm 305 420 400 420 380 368
Vertical travel mm 400 420 400 420 430 450
T-slot No. and size mm 3 x 16
Ram travel mm 312 470 500
Distance from spindle to table mm 0-415 0-405 0-350 0-450
Spindle hole taper   Standard: R8  Optional : ISO30/ISO40 Standard: ISO40
Spindle travel mm 127 mm
Spindle speed r.p.m Standard: step 16 speed  50HZ: 65-4500  60HZ: 80-5440
Optional: Variable speed 65-4500 Optional: Variable speed: 65-3750
Auto. quill feed mm/r Three steps: 0.04 (0.0015″) / 0.08 (0.003″) / 0.15(0.006″) Three Steps: 0.04 (0.0015″) / 0.08 (0.003″) / 0.15 (0.006″)
Spindle Motor kw/HP 2.25kw / 3HP 3.75kw / 5HP 3.75kw / 5HP
Head Swivel   90°
Head Tilting   45° Fix 45° Fix 45° Fix
Dimension of package One mm 1400x1476x2030 1516x1550x2080 1566x1650x2080 1800x2016x2180
Two mm 1450x1570x2080 1650x1790x2170 1720x1800x2175 1800x2200x2180
Three mm 1450x2180x2080 1650x2285x2235 - -
Gross Weight kg 1100 1160 1550 1380 1420 1650 1590 1590 1700 1750 2300 2350





Features:



  M230A:

*Double 55°dovetail guide way is adopted on Both Y and Z axis;

*Adopted strengthen rib on both sides of the column;

*The work table surface and 3 axis guide way are hardened and precision ground.



  M230B:

*Double 55°dovetail guide way is adopted on Z axis, and rectangular guide way on Y axis;

*Adopted strengthen rib on both sides of the column;

*The work table surface and 3 axis guide way are hardened and precision ground.



  M250A:

*Double 55°dovetail guide way is adopted on Both Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

*The work table surface and 3 axis guide way are hardened and precision ground.



  M250B:

*Double 55°dovetail guide way is adopted on Z axis, and rectangular guide way on Y axis;

*The guide way on saddle is lined with TF wearable material;

*The work table surface and 3 axis guide way are hardened and precision ground.



  M250:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material.



  M250C:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

* 5HP milling head motor and quill diameter is 100mm;

*Fixed structure is used to connect the mill head without adapter;



  M250D:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

* 5HP milling head motor and quill diameter is 100mm.



  M250U:

*Rectangular guide ways on Y and Z axis;

*X, Y axis adopt auto feed gear box; Feed motor: 250w; Feed rate: 15, 23, 33, 48, 78, 114, 166, 257;

*The work table surface and 3 axis guide way are hardened and precision ground.



  M300:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

* 5HP milling head motor and quill diameter is 100mm;

*The work table surface and 3 axis guide way are hardened and precision ground;

*Z axis adopts high speed lifting motor.



  M300A:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

* 5HP milling head motor and quill diameter is 100mm;

*The work table surface and 3 axis guide way are hardened and precision ground;

*Z axis adopts high speed lifting motor;

*Fixed structure is used to connect the mill head without adapter;



  M330:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

* 5HP milling head motor and quill diameter is 100mm;

*The work table surface and 3 axis guide way are hardened and precision ground;

*Z axis adopts high speed lifting motor.

* Super saddle structure.



M330A:

*Rectangular guide ways on Y and Z axis;

*The guide way on saddle is lined with TF wearable material;

* 5HP milling head motor and quill diameter is 100mm;

*The work table surface and 3 axis guide way are hardened and precision ground;

*Z axis adopts high speed lifting motor.

* Super saddle structure;

*Fixed structure is used to connect the mill head without adapter.



***Standard accessories:

Draw bar, Electric box, Working light, Hand oil pump, Tool & tool box



***Optional accessories:

Digital readout system(DRO), Machine vise, Power feed unit, Gear box power feed,  Clamping kits,  ISO40 collet chuck, R8 collet chuck, Oil collecting plate, Plastic splash guard, Cooling system
