2550KG Weight / 360 x 1250mm Table Size / Universal Swivel Head Knee Type Milling Machine / US360B
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMAC, TIMEWAY |
| Model Number: | US360B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $10,000.00/sets 1-2 sets |
| Packaging Details: | Wood case(can be fumigated) |
| Supply Ability: | 65 Set/Sets per Month |
|
Detail Information |
|||
| Table Travel (X) (mm): | 1000 | Machining Capacity: | Heavy Duty |
|---|---|---|---|
| Table Travel (Y) (mm): | 320 | Table Travel (Z) (mm): | 400 |
| Spindle Taper: | ISO40 | Range Of Spindle Speed(r.p.m): | 35 - 1600 R.p.m |
| Type: | Universal | Spindle Motor Power(kW): | 3 |
| Voltage: | 220/380V | Dimension(L*W*H): | 2220x1660x2020mm |
| Weight (KG): | 2550 | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | CNC Or Not: | Normal |
| Milling Machine: | Universal Swivel Head Knee Type Milling Machine | Table Size: | 1250x360mm |
| Diameter Of Spindle Quill: | 100mm | Spindle Rotate Speeds: | 35-1600rpm |
| Table Travel (Horizontal): | 1000mm | Table Travel (Cross): | 320mm |
| Table Travel (Vertical): | 400mm | N.W./G.W.: | 2350/2550kg |
| Number Of Axes: | 2 | Condition: | New |
| Applicable Industries: | Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction Works , Energy & Mining | Showroom Location: | Argentina, Romania, Australia, Brazil, Pakistan, Russia, Spain |
| Core Components: | Bearing, Motor, Pump, Gear | Table Travel (mm): | 1000/320/400mm |
| Port: | China Port | ||
Product Description
360 x 1250mm Table Size / Universal Swivel Head Knee Type Milling Machine / US360B
Features:
1. Both horizontal and vertical spindles, with vertical milling head can swivel ±360, realizing multiple
surface processing with workpiece static;
2. Full gear type horizontal spindle box, ISO40 spindles, vertical and horizontal milling can exchange
without rotating the ram;
3. Table surface and guideways are hardened and ground;
4. Automatic feeds on X, Y axes, motorized elevating of table on Z axis;
5. Extended length and thickness saddle, more rigid and stable.
Parameter:
| Specification | US360B |
| Spindle taper | ISO40(V), ISO40(H) |
| Diameter of spindle quill | 100mm |
| Distance from vertical spindle nose to table | 200-600mm |
| Distance from horizontal spindle centerline to table | 0-400mm |
| Distance from vertical spindle centerline to column | 300-900mm |
| Spindle rotate speeds | (11step)35-1600rpm(V),(12steps)40-1300rpm(H) |
| Distance from horizontal spindle centerline to ram | 350mm |
| Vertical milling head swivel angle | ±360° |
| Table size | 1250×360mm |
| T-slot Number/width/distance | 3/18mm/80mm |
| Table loading capacity | 400kg |
| Table travel(Horizontal/Cross/Vertical) | 1000/320/400mm |
| X, Y-axes feed speed | 22-555mm |
| X, Y-axes rapid feed speed | 1080mm/min |
| Z-axis rapid feed speed | 590mm/min |
| Column guideway type | Rectangular type |
| Cross guideway type | Rectangular type |
| Longitudinal guideway type | Dovetail type |
| Main motor | 3kw(V), 3kw(H) |
| X, Y axes feed diving motor | 750w |
| Z-axis rapid feed motor power | 1100w |
| Coolant pump power | 90w(25L) |
| Overall dimension(LxWxH) | 2220x1660x2020mm |
| Packing size(LxWxH) | 1800x1900x2250mm |
| N.W./G.W. | 2350/2550kg |
