2019 Weida X6332c Milling Machine with Range of Spindle Speed r.p.m 65 4500 r.p.m
Product Details:
| Place of Origin: | China |
| Brand Name: | TIMAC |
| Model Number: | M250C |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $9,896.00/sets 1-2 sets |
| Packaging Details: | Wooden case/Pallet(can be fumigated) |
| Supply Ability: | 500 Set/Sets per Month |
|
Detail Information |
|||
| Table Travel (X) (mm): | 820 | Machining Capacity: | Light Duty |
|---|---|---|---|
| Table Travel (Y) (mm): | 410 | Table Travel (Z) (mm): | 400 |
| Spindle Taper: | ISO40 | Range Of Spindle Speed(r.p.m): | 65 - 4500 R.p.m |
| Type: | VERTICAL | Spindle Motor Power(kW): | 3.75 |
| Voltage: | 220/380v | Dimension(L*W*H): | 1516x1550x2080mm |
| Weight (KG): | 1490 | Warranty: | 1 Year |
| Key Selling Points: | Easy To Operate | Marketing Type: | Hot Product 2019 |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | CNC Or Not: | Normal |
| Turret Milling Machine: | Turret Milling Machine | Table Size: | 254x1370mm |
| Longitudianl Travel: | 950mm | Cross Travel: | 420mm |
| Vertical Travel: | 420mm | Ram Travel: | 470mm |
| Distance From Spindle To Table: | 0-405mm | Spindle Motor: | 3.75kw |
| Head Swivel: | 90° | Number Of Axes: | 3 |
| Condition: | New | Applicable Industries: | Garment Shops, Machinery Repair Shops, Manufacturing Plant, Restaurant, Retail, Construction Works , Energy & Mining |
| Showroom Location: | Chile, Colombia, Bangladesh, South Africa, Ukraine, United States, Germany, Brazil, Indonesia | Core Components: | Motor, Gear, PLC |
| Table Travel (mm): | 820x410x400 | Port: | China Port |
Product Description
Precise Turret Milling Machine
Precise turret milling machine
High speed precision vertical turret milling machine
Pully step speed, variable(stepless) speed, invert speed type milling machines
Key Feature:
• Hardened and ground table surface;
• Universal mill head can be tilted and swiveled;
• Auto. splindle feeds with 3 steps on X, Y, Z axes;
• Spindle features micrometer depth stop;
• Work table features large clamping area;
• Powerful coolant device included in machine base.
Technical Specification:
| Model | Unit | M230A | M230B | M250 | M250A | M250B | M250U | M250C | M250D | M300 | |
| Table size | mm | 230x1067 | 254x1270 | 250x1270 | 254x1270 | 305x1370 | |||||
| 230x1246 | 254x1370 | 254x1370 | 305x1500 | ||||||||
| Longitudianl travel | mm | 650 / 840 | 850 / 950 | 770 | 850 / 950 | 870 / 1000 | |||||
| Cross travel | mm | 305 | 420 | 400 | 420 | 380 | |||||
| Vertical travel | mm | 400 | 420 | 400 | 420 | 430 | |||||
| T-slot No. and size | mm | 3 x 16 | |||||||||
| Ram travel | mm | 312 | 470 | 500 | |||||||
| Distance from spindle to table | mm | 0-415 | 0-405 | 0-350 | |||||||
| Spindle hole taper | Standard: R8 Optional : ISO30/ISO40 | Standard: ISO40 | |||||||||
| Spindle travel | mm | 127 mm | |||||||||
| Spindle speed | r.p.m | Standard: step 16 speed 50HZ: 65-4500 60HZ: 80-5440 | |||||||||
| Optional: Variable speed 65-4500 | Optional: Variable speed: 65-3750 | ||||||||||
| Auto. quill feed | mm/r | Three steps: 0.04 (0.0015″) / 0.08 (0.003″) / 0.15(0.006″) | Three Steps: 0.04 (0.0015″) / 0.08 (0.003″) / 0.15 (0.006″) | ||||||||
| Spindle Motor | kw/HP | 2.25kw / 3HP | 3.75kw / 5HP | 3.75kw / 5HP | |||||||
| Head Swivel | 90° | ||||||||||
| Head Tilting | 45° | Fix | 45° | ||||||||
| Dimension of package | One | mm | 1400x1476x2030 | 1516x1550x2080 | 1566x1650x2080 | ||||||
| Two | mm | 1450x1570x2080 | 1650x1790x2170 | 1720x1800x2175 | |||||||
| Three | mm | 1450x2180x2080 | 1650x2285x2235 | - | |||||||
| Gross Weight | kg | 1100 | 1160 | 1550 | 1380 | 1420 | 1650 | 1590 | 1590 | 1700 | |
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: 1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
2) Irrevocable LC at sight;
3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
