Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
 |
TM-250A Turret Milling Machine High Precision and CNC Multi-Axis Machining
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Timeway |
| Model Number: | TM250A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $6,800.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Type: | Universal | Range Of Spindle Speed(r.p.m): | 65 - 4500 |
|---|---|---|---|
| Number Of Axes: | 3 | No. Of Spindles: | Single |
| Machining Capacity: | Medium Duty | Spindle Taper: | ISO40 |
| Table Travel (X) (mm): | 820/920 | Table Travel (Y) (mm): | 390 |
| Table Travel (Z) (mm): | 460 | Positioning Accuracy (mm): | ±0.005 |
| Repeatability (X/Y/Z) (mm): | ±0.003 | Voltage: | 220V/380V |
| Key Selling Points: | Multifunctional | Weight (KG): | 1590 |
| Warranty: | 1 Year | Max. Table Load(kg): | 600 Kg |
| Marketing Type: | Ordinary Product | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| CNC Or Not: | Normal | Product Name: | Milling Machine |
| Machine Type: | Table Moving | After-sales Service Provided: | Service Machinery Overseas |
| Name: | Vertical Metal Machine | Keyword: | China Milling Machine |
| Application: | Metal Machining | Function: | Machining Metal |
| Precision: | High Precision | Usage: | Processing Machine |
| Condition: | New | Showroom Location: | Egypt, Canada, Turkey, Italy, France, Viet Nam, Peru, Saudi Arabia, Russia, Spain, South Korea, Chile, Romania, Bangladesh, Nigeria, Uzbekistan |
| Year: | 2023 | Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Energy & Mining, Advertising Company, Other |
| Core Components: | Bearing, Motor, Gear, Gearbox, Other | Port: | China Port |
Product Description
Products Description
TM250A
Turret Milling Machine:
Specification | Unit | TM250 |
Table size (WxL) | mm | 254x1270/254x1370 |
Table longitudinal travel | mm | 820/920 |
Table cross travel | mm | 390 |
Knee vertical travel | mm | 460 |
Knee rapid feed speed | mm/min | 345 (optional) |
Motor power | HP | 3HP (opt.: 5HP) |
Speed | rpm | |
Taper | - | R8 (opt.: ISO30/40) |
Quill travel | mm | 127 |
Quill feed rate | mm/r | 0.04/0.08/0.15 |
Swivel angle | ° | ±90° |
Tilting angle | ° | ±45° |
Distance spindle end to table | mm | 30-490 |
Motor power | HP | 5HP |
Speed | rpm | 16steps, 50HZ: 65-4500/60HZ: 80-5440 (opt.: variable speed) |
Taper | - | ISO40 |
Distance spindle center to table | mm | -490 |
Distance spindle center to ram | mm | 185 |
Ram cross travel | mm | 640 |
Ram swivel angle | ° | 180° |
Worktable swivel angle | ° | ±35° |
Net weight | kg | 1550/1590 |
Packing size (LxWxH) One | mm | 160x170x220 |
Packing size (LxWxH) Two | mm | 170x220x220 |
Positive Comments From Customers
Company Introduction
Factory Display：
Text Introduction：
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
