MD400- High Precision Milling and Drilling Machine for Medium Duty Machining Capacity
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMEWAY |
| Model Number: | MD400 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $10,000.00/sets 1-2 sets |
|
Detail Information |
|||
| Table Travel (X) (mm): | 600 | Machining Capacity: | Medium Duty |
|---|---|---|---|
| Table Travel (Y) (mm): | 260 | Table Travel (Z) (mm): | 300 |
| Spindle Taper: | MT4 | Range Of Spindle Speed(r.p.m): | 115 - 1750 R.p.m |
| Type: | VERTICAL | Spindle Motor Power(kW): | 3 |
| Voltage: | 220/380V | Dimension(L*W*H): | 1660x1340x2130 |
| Weight (KG): | 1000 | Warranty: | 1 Year |
| Key Selling Points: | Multifunctional | Marketing Type: | New Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | CNC Or Not: | Normal |
| After-sales Service Provided: | Online Support | Color: | Opitional |
| Precision: | High Precision | Usage: | Metal Parts Machining |
| Spindle Speed: | 115-1750 (8) RPM | Name: | Drilling Milling Machine |
| Product Name: | Drilling Milling Machines MD100H | Table Size: | 280x1120 |
| Processing: | Mechanical Processing | Number Of Axes: | 3 |
| Condition: | New | Applicable Industries: | Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction Works |
| Showroom Location: | Morocco, Kenya, Argentina, South Korea, Chile, UAE, Algeria, Japan, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Viet Nam, Indonesia, Mexico | Table Travel (mm): | 280x1120(1200) |
| Year: | 2023 | Core Components: | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine, Gearbox, Other |
Product Description
Products Description
MD400
Milling & Drilling Machine:
Specifications | Unit | MD400 | MD500 |
Table size | mm | 280x1120/280x1200 | 280x1120/280x1200 |
Longitudinal travel (X) | mm | 600 | 600 |
Cross travel (Y) | mm | 260 | 260 |
Vertical travel (Z) | mm | 300 | 300 |
T-slot No. and size and distance | mm | 3/14/70 | 3/14/70 |
Loading capacity | kg | 200 | 200 |
Max. drilling capacity | mm | 50 | 50 |
Max. tapping capacity | mm | M16 | M16 |
Distance from vertical spindle to table | mm | 90-410 | 110-410 |
Distance from vertical spindle to column | mm | 200-700 | 200-700 |
Vertical spindle taper | - | MT4 | ISO40 |
Verical spindle quill travel | mm | 120 | 120 |
Vertical spindle quill automatic feed | mm/r | - | 0.08/0.15/0.25 |
Vertical spindle speed | rpm | 115-1750 (8) | 90-2000 (8) |
Vertical spindle motor power | kw | 0.85/1.5 | 2.2 |
Distance from horizontal spindle center to table | mm | 0-300 | 0-300 |
Horizontal spindle taper | - | ISO40 | ISO40 |
Horizontal spindle speed | rpm | 40-1300 (12) | 40-1300 (12) |
Horizontal spindle motor power | kw | 2.2 | 2.2 |
X/Y-axis feed speed | mm/min | X: 24-720 | X: 36-1100 |
Z-axis rapid feed speed | mm/min | - | - |
Mill head swivel angle | ° | ±45° | ±45° |
Machine dimensions (LxWxH) | mm | 1660x1340x2130 | 1660x1340x2130 |
Net weight/gross weight | kg | 1250/1350 | 1300/1380 |
