Professional Machining CNC Bed-Type Milling Machine Precision Table Travel 600x2500mm
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | TIMEWAY |
| Model Number: | BM716 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $50,000.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Table Travel (X) (mm): | 1800 | Machining Capacity: | Medium Duty |
|---|---|---|---|
| Table Travel (Y) (mm): | 700 Mm | Table Travel (Z) (mm): | 100 Mm |
| Spindle Taper: | ISO50 | Range Of Spindle Speed(r.p.m): | 6 - 1500 R.p.m |
| Type: | VERTICAL | Spindle Motor Power(kW): | 11 |
| Voltage: | Customer Requirement | Dimension(L*W*H): | 4380x2520x2800mm |
| Weight (KG): | 9000 | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Name: | Milling |
| Machine Type: | Milling Machine Vertical Universal | Product Name: | Milling Machine Repairing |
| Keyword: | Milling Machine Manual | Function: | Milling Cutting |
| Application: | Metal Machining | CNC Or Not: | Normal |
| Usage: | General | Color: | Custom-made |
| Precision: | Precision | Number Of Axes: | 3 |
| Condition: | New | Showroom Location: | None |
| Core Components: | Motor | Table Travel (mm): | 600x2500 |
| Year: | 2023 | Applicable Industries: | Manufacturing Plant, Fresadora Universal Para Metal ZX6350A Milling Mac |
| Port: | China Port | ||
Product Description
Products Description
SPECIFICATION | UNIT | BM716 |
Table size | mm | 600x2500 |
Longitudinal travel (X) | mm | 1800 |
Cross travel (Y) | mm | 700 |
T slot (No./width/distance) | mm | 5/20/100 |
Spindle taper | ISO50 | |
Verical spindle speed | rpm | 6-1500 (2steps) |
Distance from horizontal spindle axis to table | mm | 8-660 |
Distance from vertical spindle axis to column | mm | 8-660 |
Distance from vertical spindle nose to table | mm | 0-700 |
X/Y-axis feed speed | mm/min | 2.5-3000 |
X/Y-axis rapid feed speed | mm/min | 6000 |
Z-axis feed speed | mm/min | 2.5-2500 |
Z-axis rapid feed speed | mm/min | 3000 |
Main motor power | kw | 11 |
X/Y/Z-axis feed motor torque | NM | 18/23/18 |
Coolant pump power | kw | 0.09 |
Machine dimensions (L脳W脳H) | mm | 4380x2520x2800 |
Machine weight | kg | 9000 |
Draw bar Milling chuck (ISO50) Taper shell end mill holder (ISO50) Middle cover Work lamp Oil gun General tools Foundation bolt Operation manual | • 3 axes DRO; • Ball rolling lead screw for X & Y axes; • Machine vice 200mm; • Universal dividing head; • Rotary table 500mm; • Spindle guard(eye protection); |
Why Choose Us
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
Want to Know more details about this product
