Retail CNC Pipe Threading Oil Country Lathe 440mm Spindle Bore Max. Length 1500-3000mm
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | Timeway |
| Model Number: | QK-440 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $63,000.00/sets 1-2 sets |
| Packaging Details: | Wooden cases(can be fumigated) |
| Supply Ability: | 150 Set/Sets per Month |
|
Detail Information |
|||
| Type: | Horizontal | Max. Length Of Workpiece (mm): | 15003000 Mm |
|---|---|---|---|
| Structure: | Flat Bed Lathe | Machining Capacity: | Light Duty |
| Width Of Bed (mm): | 755 Mm | Spindle Motor Power(kW): | 22 |
| No. Of Spindles: | Single | Number Of Axes: | 2 |
| Travel (X Axis)(mm): | 520 Mm | Travel (Z Axis)(mm): | 300 Mm |
| Dimension(L*W*H): | 6500*2220*2120 | CNC Control System: | FANUC/SIEMENS/GSK |
| Tool Post Stations: | 4 | Weight (KG): | 13000 |
| Warranty: | 1 Year | Key Selling Points: | High-accuracy |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Product Type: | Cnc Horizontal Turning Lathe Machine |
| CNC Or Not: | CNC | Machine Type: | CNC Pipe Threading Lathe |
| Name: | High Precision CNC Lathe Machine | Keyword: | Cnc Lateh Machine |
| Color: | Customer Optional | Max. Length Of Workpiece: | 15003000 |
| Control System: | SIEMENS GSK FANUC (optional) | Processing: | High Accuracy High Speed |
| Function: | Cnc Pipe Thread | Condition: | New |
| Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Retail | Showroom Location: | Egypt, Brazil, Russia |
| Marketing Type: | Hot Product 2019 | Core Components: | Bearing, Motor |
| Year: | Least Day | Max. Spindle Speed (r.p.m): | 205 R.p.m |
| Spindle Bore(mm): | 440mm | Max. Turned Length (mm): | 2750 |
| Port: | China Port | ||
Product Description
Product Description
Applications of the CNC oil country lathe:
The CNC oil country lathe meets the special requirements of users in the petroleum, geological, mining and chemical industries, and in agricultural irrigation and drainage, it is able to cut various straight and taper pipe threads of union joints, drill rods, casting pipes, drain pipes, well castings and water pump pipes more economically and efficiently as compared with the engine lathe, however, it may serve as an engine lathe to cut various metric, withworth and module threads, shafts and disks.
››››› The lathe is equipped with a taper turning attachment which can work out long taper.
››››› The lathe is equipped with double chucks which can powerful clamp long parts.
››››› The lathe is equipped with rear support which can auxiliary support longer parts.
››››› The lathe is equipped with double chucks which can powerful clamp long parts.
››››› The lathe is equipped with rear support which can auxiliary support longer parts.
Specification
Specifications | Unit | QK-440 |
Swing over bed | mm | 1000 |
Swing over cross slide | mm | 610 |
Distance between centers | mm | 1500/3000 |
Pipe threading range | mm | 270-430 |
Bed width | mm | 755 |
Max. load capacity | kg | 6000 |
Spindle bore | mm | 440 |
Spindle speed steps | steps | stepless (3shifts) |
Spindle speed | rpm | 8-205 |
Chuck size | mm | 1000 |
Chuck type (electric) | - | 4-jaw |
Turret type (electric) | - | V4 |
Tool shank size | mm | 40x40 |
X-axis travel | mm | 520 |
Z-axis travel | mm | 1250 |
X-axis rapid feed speed | mm/min | 4000 |
Z-axis rapid feed speed | mm/min | 4000 |
Tailstock quill diameter | mm | 140 |
Tailstock quill taper | - | MT6 |
Tailstock quill travel | mm | 300 |
Main motor power | kw | 22 |
Coolant motor power | kw | 0.125 |
Machine dimensions | mm | 5000/6500x2200x2200 |
Machine weight | kg | 13000/14000 |
