| Place of Origin: | Henan, China |
| Brand Name: | TIMAC, TIMEWAY |
| Model Number: | Q-280/Q-330 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $60,000.00/sets 1-1 sets |
| Packaging Details: | Wooden case(can be fumigated) |
| Supply Ability: | 100 Set/Sets per Month |
|
Detail Information |
|||
| Max. Length Of Workpiece (mm): | 6000 | Range Of Spindle Speed(r.p.m): | 20 - 400 R.p.m |
|---|---|---|---|
| Machining Capacity: | Heavy Duty | Width Of Bed (mm): | 600 |
| Type: | Horizontal | Spindle Motor Power(kW): | 15 |
| Voltage: | 380V, 50HZ/60HZ | Dimension(L*W*H): | 8600x1700x1600 |
| Weight (KG): | 12000 KG | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Marketing Type: | Ordinary Product |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Machine Type: | Horizontal Pipe Threading Lathe |
| Z-axis Guideway Style: | Flat- V Type Rails | X-axis Guideway Style: | Dovetail Type Rails |
| X/Z-axis Rails Treatment: | Hardened & Ground & Hand Scrap | Working Accuracy: | IT6 |
| Max. Swing Over Bed: | 800mm | Spindle Bore: | 280mmm |
| Spindle Speed: | 20-400rpm (4shifts, Stepless In Shift) | Chuck Diameter: | 4-jaw Chuck, 630mm |
| Loading Capacity: | 4000kg | Condition: | New |
| Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction Works , Energy & Mining | Showroom Location: | Egypt, Canada, Turkey, United States, Italy, France, Philippines, Brazil, Peru, Pakistan, India, Mexico, Russia, Spain, Chile, Colombia, Romania, Uzbekistan, Malaysia, Australia |
| Core Components: | Bearing, Pump, Gear, Motor, Gearbox, PLC | Spindle Bore(mm): | 280 |
| Max. Turned Length (mm): | 5850 Mm | Year: | 2023 |
| Port: | China Port | ||
√ Big bore chuck (Front & Rear) √ Dead centers √ 4-station tool-post √ Taper turning attachment √ Cooling system √ Work lamp √ Chip collecting plate √ Oil gun √ Manual moving tailstock √ Tools & tool-box √ Leveling wedge & bolts √ Operation manual (English) | _ Steady rest _ Follow rest _ Rear support for long pipe _ Live centers _ 2 or 3-axis DRO _ Quick changing tool post _ Chuck guard _ Tool post guard _ Rear splash guard |
Specification | Unit | Q-280 | Q-330 |
Max. swing over bed | mm | 1000 | 1000 |
Max. swing over cross slide | mm | 610 | 610 |
Distance between centers | mm | 1500/3000 | 1500/3000 |
Pipe threading range | mm | 130-270 | 190-320 |
Bed width | mm | 755 | 755 |
X-axis travel | mm | 520 | 520 |
Z-axis travel | mm | 1350/2850 | 1350/2850 |
Max. load capacity | kg | 6000 | 6000 |
Spindle bore | mm | 280 | 330 |
Spindle speed steps | steps | 12 | 9 |
Spindle speed | rpm | 16-380 | 7.5-280 |
Chuck size | mm | 800 | 780 |
Chuck type | - | 4-jaw manual | 4-jaw electric |
Turret type (manual) | - | V4 | V4 |
Tool shank size | mm | 45x45 | 45x45 |
X-axis feed range(steps) | mm/r | 0.05-1.5(40) | 0.05-0.75(32) |
X-axis rapid feed | mm/min | 1870 | 1870 |
Z-axis feed range(steps) | mm/r | 0.1-3(40) | 0.1-1.5(32) |
Z-axis rapid feed | mm/min | 3740 | 3740 |
No. of Metric thread and range | mm | 1-30(30) | 1-15(23) |
No. of Inch thread and range | TPI | 1-28(27) | 2-28(22) |
Tailstock quill diameter | mm | 140 | 140 |
Tailstock quill taper | - | MT6 | MT6 |
Tailstock quill travel | mm | 300 | 300 |
Main motor power | kw | 22 | 22 |
Rapid motor power | kw | 1.5 | 1.5 |
Coolant motor power | kw | 0.125 | 0.125 |
Machine dimensions (LxWxH) | mm | 4800/6400x2100x1600 | 4900/6400x2100x1650 |
Machine weight | kg | 10000/11500 | 11500/13000 |
